The winding is a contact method. The arms retract by moving horizontally according to the winding diameter. Contact pressure can always be applied toward the center of the product, thus control from low contact pressure can be realized regardless of tension, greatly improving product quality.
The product unloader is equipped in front for the winding product (optional). Unlike conventional machines, it does not require to unload from the side of the machine. It only needs small installation space.
The operating conditions can be set to any taper and can be adjusted to various film conditions. Also, it has a storage function in the internal memory, making it easy to manage product type parameters.
Compatible web materials | OPP, CPP, PET |
---|---|
Web width | 2200mm~800mm |
Unwinding diameter | Φ1000mm |
Winding diameter | Φ600mm |
Machine speed | 600m/min |
Shear cutter
Cutter automatic positioning device
Product roll unloading device
Winding arm automatic positioning device
Built-in trim winder
