An overhead path is used for clean room measures.
The roller layout is to prevent getting dust or scratches in the product.
This machine also comes with unloading device. It does not receive product directly on the conveyor.
The vacuum device on the cutter eliminates slitting dust.
Equipped with a cross cutter and it can cut products at right angles.
Operating conditions can be stored in the internal memory with the touch panel. (optional)
It gives easy product management. (standard function)
Compatible web materials | PET and Two-layers film |
---|---|
Web width | 700mm~1700mm |
Unwinding diameter | Φ800mm |
Winding diameter | Φ600mm |
Machine speed | 200m/min |
Shear cutter
Web roll hydraulic lifting device
Product roll unloading device, etc.
Please contact us for any inquiries and quotes of slitters and rewinders.
