Even thickness materials such as paper can be wound into a large diameter by using both a surface and a center drive winders.
Contact-type roller control enables control from low pressure.
Since the main body frame of the cutter unit moves and the distance from the cutter to the rewind shaft does not change, the edge face accuracy of the product roll is improved.
The web roll for an unwind unit can be set easily without a shaft.
By equipping an extracting device to the rewind shaft (optional), it is easy to unload the product rolls.
The time to restart is short, so it increases productivity.
Operating conditions can be stored in internal memory with the touch panel. (optional)
It gives easy product management. (standard function)
Compatible web materials | Paper, silicon paper, vapor deposition paper, thick sheet |
---|---|
Web width | 1000mm~1800mm |
Unwinding diameter | Φ1000mm |
Winding diameter | Φ1000mm |
Machine speed | 400m/min |
Web roll setting device
Winding shaft extraction device
Shear cutter,Independent holder unit type, etc.
Support roll
