500m / min high speed slit
Large capacity with unwinding diameter of 1,000 mm and winding diameter of 600 mm
40% reduction in operating moves
Various easy-operation options
Wide tension range 30-200 N/m
Horizontal movement touch roller
High-precision shear cutter mechanism
Industry's smallest class installation area
40% lighter than the conventional machine
Easy to relocate with casters
Warning light can be seen from all directions.
Effective covering.
Sharp appearance in bright colors.
| Model | eS! |
|---|---|
| Compatible web materials | Single layer and laminated film |
| Web width | 300mm~1,200mm |
| Roller length | 1,300mm |
| Roller feeding diameter | Φ1,000mm |
| Winding diameter | Φ600mm |
| Web weight | 1,000kg |
| Core | Inner diameter 3 "cardboard core |
| Machine speed | 500m/min |
| Tension | Unwind 50N-250N / whole width Rewind 30N~200N/m |
| Electric capacity | 200/220V, 50/60Hz |
| Air source | 0.5MPa,150NL/min (dry air) |
| Slit method | •Razor cut •Shear cut (optional) |
| Installation space | 2,400mm(W)×1,900mm(L)×1,815mm(H) Basic 3,650mm(W)×2,035mm(L)×2,015mm(H) Full specs |
Please contact us for any inquiries and quotes of slitters and rewinders.
