Combined method of surface drive by horizontal movement contact rollers and center driving of winding shaft.
Easy lower blade replacement.
Felto type cleaner is equipped on the upper blade.
Easy product unloading
Remove the slit selvage with cut blower.
| Compatible web materials | Hard aluminum foil |
|---|---|
| Web width | 300mm~700mm |
| Roller length | 800mm |
| Unwinding diameter | Φ700mm |
| Winding diameter | Φ400mm |
| Web weight | Max. 1000kg |
| Core | 3 "cardboard core |
| Machine speed | 350m/min |
| Tension | 50N~300N |
| Slit method | Shear cutter |
| Installation space | 2500W×3000D×1750H |
Please contact us for any inquiries and quotes of slitters and rewinders.
