400m/min high-speed winding
Lifting device as standard equipment
Intuitive operation
Wide tension range: 20–250N
Higher tension accuracy
Proximity roller as standard equipment
The smallest installation area in the industry
Equipped with casters for easy movability
Simple structure
Warning light band that are visible from all directions
Effective cover
Sleek design with bright colors
| Model | eR! |
|---|---|
| Compatible web materials | Single layer and laminated film |
| Web width | 300–1,200mm |
| Roller length | 1,300mm |
| Roller feeding diameter | Φ800mm |
| Winding diameter | Φ800mm |
| Web weight | 500kg |
| Core | Inner diameter 3" cardboard core |
| Machine speed | 400m/min |
| Tension | 20N–250N |
| Weight | 2.7t |
| Electric capacity | 200/220V, 50/60Hz |
| Air source | 0.5Mpa |
| Installation space | 2,360mm (W) × 1,880mm (L) × 2,225mm (H) |
Please contact us for any inquiries and quotes of slitters and rewinders.
